HADW Series

The electric and air supply is on, and the machine is in ready mode. Set up the timing for rapid descending and pressurizer descending time.
To position the switch to manual drive, then press down the rapid descending button so the principal axis is falling down quickly. Press down the pressurizer button to reduce its pressure, then release the button and the principal axis rises to reposition.
To push the operation on the automatic switch: Press down the two automatic buttons simultaneously and then release. The principal axis begins to get down rapidly, and when it starts to pressurize, it returns when the time for supercharging is up.
If any emergency occurs, please press down the jerk button to reposition the principal axis and stop the machine.

CONTACT US

Parameters	HADW-1.5T	HADW-3T
Max Working Height (mm)	300	300	300	300
Specifications for hydraulic cylinders (mm)	Φ50×150	Φ63×150	Φ80×150	Φ100×150
Total Stroke (mm)	150	150	150	150
Cylinder Adjustable Stroke (mm)	50	50	50	50
Supercharging Stroke (mm)	88	55	34	21
Area of Working Bench (mm)	360×240	360×240	360×240	360×240
Power Supply AC, 50Hz	220V	220V	220V	220V
Weight (Kg)	160	162	165	178
Working Air Pressure (MPa)	Supercharging Pressure
0.3 MPa	1131 Kg	1809 Kg	2885 Kg	4599 Kg
0.4 MPa	1508 Kg	2412 Kg	3847 Kg	6133 Kg
0.5 MPa	1885 Kg	3015 Kg	4809 Kg	76666 Kg
0.6 MPa	2262 Kg	3618 Kg	5770 Kg	9199 Kg
0.7 MPa	2640 Kg	4221 Kg	6732 Kg	10732 Kg
